Fiber Indexing by CommScope
CommScope’s pre-connectorized plug-and-play solution allows to:
- deploy fiber up to 75% faster
- reduce the amount of cable required by up to 70%
- eliminate the need for fiber splicing
How? By changing from a star to a daisy-chain topology for connecting service terminals, and consolidating functionality into the service terminal. By using hardened service terminals with hardened multi-fiber connectors, this architecture combines the advantages of a daisy chain-topology with plug-and-play connectivity.
How Does Fiber Indexing Compare?
|
Traditional Network |
Fiber Indexing Network |
Benefits of Indexing |
Fiber Distribution Hub |
Serves ~240 homes |
Serves ~240 homes |
- |
Fiber connections |
Spliced |
Pre-connectorized cables to the terminals |
10-15 minutes to plug in cables compared to over 4 hours for splicing individual fibers |
Network topology |
Star (hub and spoke) |
daisy-chain |
Standardized lengths of cables simplifies logistics |
Total cable length |
20,025 Feet |
5,530 Feet |
70% reduction in cable laying costs and conduit space required |
Service Terminal Functionality |
Fan-out (breaks out 8-fiber cable to individual ports) |
Fan-out, splitter, and pass-through |
Functions of network elements are redistributed to support indexing (no net benefit |
Drop Cable |
Single hardened drop cable |
Single hardened drop cable |
|
